Pi Agent QQBot

Pi Agent QQBot

English | 简体中文

English

Connect a QQ C2C conversation to the native Pi session that is already running in your terminal, using the official QQ Bot API.

Why This Exists

QQ is not a separate agent. It is a second input surface for the same Pi runtime: terminal and QQ share the working directory, model, tools, context, session history, and extension-created interaction UI.

Use the same live coding session from QQ when you are away from the terminal, without creating a second agent, duplicating context, or exposing a general-purpose remote command shell.

Requirements

  • Pi >=0.82.0 <1.0.0
  • Node.js >=22.19.0
  • An official QQ bot with C2C direct messages enabled
  • Native Windows, macOS, or Linux

WSL path translation and mixed Windows/WSL installations are not supported.

Highlights

  • Bind one configured QQ C2C owner to the active native Pi session.
  • Work from QQ with the same workspace, model, context, and session history.
  • Use QQ Keyboard controls for models, thinking levels, and native Pi sessions.
  • Deliver ctx.ui.confirm(), select(), and input() to both terminal and QQ. The first response from either side wins.
  • Operate extension-created ctx.ui.custom() remotely through a TUI snapshot, keys, and text input.
  • Receive images, voice, documents, and ordinary files without extension-level file count, type, or size quotas.
  • Send verified local files through QQ's official chunked-upload API.
  • Transfer Gateway ownership between local Pi processes without stopping either process.

Install

Install the published npm package:

pi install npm:pi-agent-qqbot

You can also install a tagged GitHub release:

pi install git:github.com/gtiders/pi-agent-qqbot@v1.0.4

When HTTPS access to GitHub is unavailable, use SSH:

pi install git:git@github.com:gtiders/pi-agent-qqbot@v1.0.4

Completely exit and restart Pi after installation or upgrade.

Configure

Create ~/.pi/agent/pi-agent-qqbot.json. On Windows, this is %USERPROFILE%\.pi\agent\pi-agent-qqbot.json.

{
  "schemaVersion": 5,
  "appId": "YOUR_QQBOT_APP_ID",
  "clientSecret": "YOUR_QQBOT_APP_SECRET",
  "sandbox": true,
  "ownerOpenId": "",
  "link": { "conflictPolicy": "ask" },
  "inboundMedia": { "deniedKinds": [], "deniedExtensions": [] },
  "outboundMedia": {
    "enabled": false,
    "deniedRoots": [],
    "deniedKinds": [],
    "deniedExtensions": []
  },
  "logging": { "level": "info" }
}

Only schema 5 is accepted. Earlier configurations are neither read nor migrated. For first-time setup, leave ownerOpenId empty and use /qqbot-start to discover and confirm it locally.

Field Meaning
appId QQ bot application ID.
clientSecret QQ bot secret. Never commit a real value.
sandbox Use QQ's sandbox endpoint when true.
ownerOpenId The only QQ C2C user allowed to access Pi. Leave it empty only during first-time bootstrap.
link.conflictPolicy ask requests terminal approval before takeover; takeover transfers ownership automatically.
inboundMedia.deniedKinds Deny image, video, voice, or file; an empty list denies no type.
inboundMedia.deniedExtensions Deny file extensions such as .exe; an empty list denies none.
inboundMedia.stt Optional OpenAI-compatible speech-to-text settings: baseUrl, apiKeyEnv, and model.
outboundMedia.enabled Master switch for local file delivery; defaults to false.
outboundMedia.deniedRoots Real directory roots that must never be sent; an empty list permits every path readable by the current account.
outboundMedia.deniedKinds Deny outbound media types; an empty list denies none.
outboundMedia.deniedExtensions Deny outbound extensions; an empty list denies none.
logging.level error, info, or debug.

Media policies use denylist semantics. An omitted field or empty list adds no product-level restriction. QQ platform limits and file-integrity checks still apply.

Start and Link

The extension does not connect to QQ automatically. For normal use, run this command in the local terminal for each new Pi process:

/qqbot-link

For first-time setup only: save appId and clientSecret, leave ownerOpenId empty, run /qqbot-start, then send any C2C message to the bot. Pi displays the detected user_openid locally; after terminal confirmation it saves the value. Run /qqbot-link afterwards.

Local command Purpose
/qqbot-start First-time bootstrap only. Temporarily starts the Gateway to discover the first private sender OpenID; terminal confirmation writes it to the config and stops bootstrap.
/qqbot-stop Stop transport only; preserve the link and native Pi session.
/qqbot-link Start the QQ Gateway and bind the configured owner to the current Pi runtime.
/qqbot-unlink Remove the logical link and invalidate pending QQ replies.
/qqbot-status Show Gateway, ownership, link, session, model, and queue state.
/qqbot-takeover Take Gateway ownership from another local Pi process.

QQ cannot run /qqbot-* commands.

QQ Commands

QQ commands are explicitly allowlisted and appear as a Keyboard when supported by the client.

Command Purpose
/help Show the command menu.
/status Show the active link and Pi state.
/model [provider/model] Browse, search, or switch the active model.
/thinking [level] Show or change the thinking level.
/new [name] Create a native Pi session, optionally named.
/sessions [query] List or search native Pi sessions.
/resume <id-or-name> Switch to a uniquely matching native Pi session.
/name <name> Rename the current session.
/compact [instructions] Compact the active context.
/stop Abort the active Pi turn.

Normal QQ text is injected into the linked Pi session and uses Pi's native follow-up delivery while Pi is busy. Only output from QQ-originated turns is returned to QQ; output from terminal-originated turns remains in the terminal.

Shared Interaction UI

When a QQ-originated turn opens ctx.ui.confirm(), ctx.ui.select(), or ctx.ui.input(), both QQ and terminal receive the interaction. The first side to complete it wins and invalidates the other side.

For extension-created ctx.ui.custom(), both surfaces operate the same component instance. QQ receives a 72-column TUI snapshot with terminal control sequences removed, plus directional, paging, Home/End, Tab, space, backspace, delete, submit, cancel, and refresh controls. Normal QQ text is injected as terminal bracketed-paste input, including into password fields.

Pi core TUI, external PTY programs, and custom UI opened only by terminal-originated turns are outside this relay's scope.

Media

Inbound media has no extension-level count, type, individual-size, or total-size quotas. Images go to image-capable models; supported documents are extracted within remaining context budget; voice uses QQ ASR text when available; unknown files remain as temporary local resources for Pi tools.

Inbound downloads still enforce HTTPS, SSRF protection, bounded redirects, cancellation, and stalled-network detection.

With outbound media enabled, the qq_send_local_file tool can send a local file only to the original conversation of the current QQ turn. Candidates are checked with realpath, regular-file identity, hard-link, symlink/junction, and rename-race validation. QQ's 200 MB upload limit and passive-reply count remain platform constraints.

Current Boundaries

  • One configured QQ C2C owner only. Group messages and other users are ignored before attachment handling and agent work.
  • The Gateway does not start automatically with the extension. Run /qqbot-link for normal operation.
  • Pi 0.82 can discover Skills, prompt templates, and extension commands, but does not expose a complete public input-dispatch API. QQ therefore cannot generically execute every Skill, template, or third-party slash command; it supports only the allowlisted commands above.
  • Restart Pi completely after upgrading an installed package.

Troubleshooting

  • Invalid configuration: verify schemaVersion, appId, clientSecret, and ownerOpenId.
  • No QQ response: run /qqbot-status, then run /qqbot-link locally.
  • Missing ownerOpenId: leave it empty, run /qqbot-start, message the bot from QQ, and confirm the displayed OpenID in the terminal.
  • Gateway owned by another Pi: run /qqbot-takeover, or retain conflictPolicy: "ask" and approve in the terminal.
  • Cannot send local files: set outboundMedia.enabled to true, then restart Pi.
  • QQ buttons unavailable: send the corresponding text command shown on the card.

Development

See the development guide for architecture, development, and release procedures, and CHANGELOG for release history.

License

Apache-2.0

简体中文

通过 QQ 官方机器人 API，将一个 QQ 私聊连接到终端中正在运行的原生 Pi 会话。

为什么需要它

QQ 不是另起一个 Agent，而是同一 Pi runtime 的第二个输入端：终端与 QQ 共享工作目录、模型、工具、上下文、会话历史，以及扩展创建的交互界面。

离开终端时也能从 QQ 继续使用同一个实时编码会话，无需另起 Agent、复制上下文，也不会把 Pi 暴露成通用远程命令终端。

环境要求

  • Pi >=0.82.0 <1.0.0
  • Node.js >=22.19.0
  • 已启用 C2C 私聊消息的 QQ 官方机器人
  • 原生 Windows、macOS 或 Linux

不支持 WSL 路径转换，也不支持 Windows/WSL 混合安装。

主要能力

  • 将唯一配置的 QQ C2C owner 绑定到当前原生 Pi 会话。
  • 从 QQ 操作同一工作目录、模型、上下文和会话历史。
  • 使用 QQ Keyboard 切换模型、思考等级和原生 Pi 会话。
  • 将 ctx.ui.confirm()、select()、input() 同时发送到终端和 QQ，任意一端先完成即生效。
  • 通过 TUI 快照、按键和文字输入远程操作扩展创建的 ctx.ui.custom()。
  • 接收图片、语音、文档及普通文件，不增加扩展层文件数量、格式或大小配额。
  • 通过 QQ 官方分片上传 API 发送经过本地文件身份校验的文件。
  • 在本机多个 Pi 进程间转移 Gateway 所有权，不终止任何 Pi 进程。

安装

安装 npm 正式版本：

pi install npm:pi-agent-qqbot

也可以从 GitHub 的版本标签安装：

pi install git:github.com/gtiders/pi-agent-qqbot@v1.0.4

如果本机无法通过 HTTPS 连接 GitHub，可使用 SSH：

pi install git:git@github.com:gtiders/pi-agent-qqbot@v1.0.4

安装或升级后必须完整退出并重新启动 Pi。

配置

创建 ~/.pi/agent/pi-agent-qqbot.json。Windows 路径为 %USERPROFILE%\.pi\agent\pi-agent-qqbot.json。

{
  "schemaVersion": 5,
  "appId": "YOUR_QQBOT_APP_ID",
  "clientSecret": "YOUR_QQBOT_APP_SECRET",
  "sandbox": true,
  "ownerOpenId": "",
  "link": {
    "conflictPolicy": "ask"
  },
  "inboundMedia": {
    "deniedKinds": [],
    "deniedExtensions": []
  },
  "outboundMedia": {
    "enabled": false,
    "deniedRoots": [],
    "deniedKinds": [],
    "deniedExtensions": []
  },
  "logging": {
    "level": "info"
  }
}

扩展只接受 schema 5，不读取也不迁移过时配置。首次配置时可将 ownerOpenId 留空，通过 /qqbot-start 在本地发现并确认写入。

字段 含义
appId QQ 机器人应用 ID。
clientSecret QQ 机器人密钥，不得提交真实值。
sandbox true 表示使用 QQ 沙箱端点。
ownerOpenId 唯一允许访问 Pi 的 QQ C2C 用户；仅首次引导时可留空。
link.conflictPolicy ask 在接管前请求终端确认；takeover 自动转移所有权。
inboundMedia.deniedKinds 禁止 image、video、voice 或 file；空数组表示不禁止类型。
inboundMedia.deniedExtensions 禁止 .exe 等扩展名；空数组表示不禁止扩展名。
inboundMedia.stt 可选的 OpenAI 兼容语音转写配置：baseUrl、apiKeyEnv、model。
outboundMedia.enabled 本地文件出站总开关，默认 false。
outboundMedia.deniedRoots 永远禁止发送的真实目录根路径；空数组允许所有当前账户可读路径。
outboundMedia.deniedKinds 禁止出站媒体类型；空数组表示不禁止类型。
outboundMedia.deniedExtensions 禁止出站文件扩展名；空数组表示不禁止扩展名。
logging.level error、info 或 debug。

媒体配置统一采用黑名单语义：字段缺失或数组为空表示不增加产品限制。QQ 平台硬限制和文件完整性校验仍然生效。

启动与绑定

扩展加载时不会自动连接 QQ。正常使用时，每个新的 Pi 进程都需要在本地终端执行：

/qqbot-link

仅首次配置：先写入 appId 和 clientSecret，将 ownerOpenId 留空，执行 /qqbot-start，再从 QQ 私聊机器人发送任意消息。Pi 会在本地显示收到的 user_openid；终端确认后自动写入配置。随后执行 /qqbot-link。

本地专用命令：

命令 作用
/qqbot-start 仅首次引导使用。临时启动 Gateway 发现第一位私聊用户的 OpenID；终端确认后写入配置并停止引导。
/qqbot-stop 只停止传输，保留 link 和当前原生 Pi 会话。
/qqbot-link 启动 QQ Gateway，并将配置的 owner 绑定到当前 Pi runtime。
/qqbot-unlink 解除逻辑 link，并使未完成的旧 QQ 回复失效。
/qqbot-status 查看 Gateway、所有权、link、会话、模型和队列状态。
/qqbot-takeover 从本机另一个 Pi 进程接管 Gateway。

QQ 端不能执行任何 /qqbot-* 命令。

QQ 命令

QQ 命令采用显式白名单，并在客户端支持时显示 Keyboard：

命令 作用
/help 显示命令菜单。
/status 查看当前 link 和 Pi 状态。
/model [provider/model] 浏览、搜索或切换当前模型。
/thinking [level] 查看或切换思考等级。
/new [name] 新建原生 Pi 会话，可同时命名。
/sessions [query] 列出或搜索原生 Pi 会话。
/resume <id-or-name> 切换到唯一匹配的原生 Pi 会话。
/name <name> 重命名当前会话。
/compact [instructions] 压缩当前上下文。
/stop 中止当前 Pi 回合。

普通 QQ 文本会注入已绑定的 Pi 会话；Pi 忙碌时按原生 follow-up 投递。只有 QQ 发起的回合会回复 QQ，终端发起的输出只留在终端。

双端交互界面

QQ 发起的回合打开 ctx.ui.confirm()、ctx.ui.select() 或 ctx.ui.input() 时，终端与 QQ 会同时收到交互。任意一端最先完成即生效，另一端随即失效。

扩展创建的 ctx.ui.custom() 在两端共享同一个组件实例。QQ 会收到去除终端控制序列后的 72 列 TUI 快照，并提供方向键、翻页、Home/End、Tab、空格、退格、删除、确认、取消和刷新。普通 QQ 文本按终端 bracketed paste 输入，包括密码字段。

Pi 核心 TUI、外部 PTY 程序，以及仅由终端回合打开的自定义界面不在代理范围内。

媒体

入站媒体没有扩展层数量、格式、单文件或总大小配额。图片会传给支持图片的模型，已支持的文档按剩余上下文预算提取，语音优先使用 QQ ASR 文本，未知文件保留为临时本地资源供 Pi 工具读取。

入站下载仍强制 HTTPS、SSRF 防护、有限重定向、取消处理和网络停滞检测。

启用出站媒体后，qq_send_local_file 工具只能向当前 QQ 回合的原始会话发送本地文件。候选文件会经过 realpath、普通文件身份、hard-link、symlink/junction 和 rename-race 校验。QQ 的 200 MB 上传上限与被动回复次数仍是平台约束。

当前边界

  • 只支持一个配置的 QQ C2C owner；群消息和其他用户会在附件处理与 Agent 工作前被忽略。
  • Gateway 不会随扩展自动启动；日常运行请执行 /qqbot-link。
  • Pi 0.82 可以发现 Skills、提示词模板和扩展命令，但没有公开完整输入分发 API。因此 QQ 不能通用执行任意 Skill、模板或第三方 slash command，只能使用上面的白名单命令。
  • 升级已安装包后必须完整重启 Pi。

故障排查

  • 提示配置无效：检查 schemaVersion、appId、clientSecret 和 ownerOpenId。
  • QQ 没有响应：先运行 /qqbot-status，再在本地执行 /qqbot-link。
  • 缺少 ownerOpenId：将其留空，执行 /qqbot-start，从 QQ 向机器人发消息，并在终端确认显示的 OpenID。
  • Gateway 被其他 Pi 占用：执行 /qqbot-takeover，或保留 conflictPolicy: "ask" 并在终端批准。
  • 无法发送本地文件：将 outboundMedia.enabled 设置为 true，然后重启 Pi。
  • QQ 按钮不可用：直接发送卡片中显示的对应文字命令。

开发

开发、架构与发布流程见 开发指南，发布记录见 CHANGELOG。

License

Apache-2.0
